Oase Bio Tec ScreenMatic 145000

The BioTec ScreenMatic² 145000 flow-through filter adds a new size to the BioTec ScreenMatic² product range (40000, 60000, 90000, 145000). Guarantees excellent cleaning results for ponds up to 73 m³ with fish stocking. The inlet and return (DN110) are located on one side for easy handling. Long service life thanks to automatic coarse dirt separation before entering the filter. The filter belt cleans itself automatically. 2-year guarantee + 1-year request guarantee.

  • GUARANTEED: Includes OASE clear water guarantee
  • LOW MAINTENANCE: Coarse dirt is removed before it enters the filter
  • SELF-CLEANING: The filter belt is automatically driven; adjustable automatic cleaning system, which controls the belt run based on the degree of contamination, including LED function check
  • CONVENIENT: Filter sponges can be cleaned directly in the filter
  • CLEAN AND TIDY: Bottom drain with slide to remove dirt from the filter system
  • SMART COMBO: Different filter media for optimal development of filter biology
  • EXTRA FOR THREAD ALGAE: Use of PhosLess filter cartridges for reducing thread algae (optional accessory)
  • SUITABLE PUMPS: Optimally matched to OASE AquaMax Eco filter pumps
  • GOOD PARTNERS: Direct connection option for UVC Bitron C and Eco clarifiers
  • DOESN'T CLOG: Uniform water distribution on the filter belt
  • PRACTICAL: Large-volume dirt basket with easy cleaning
Specifications
Product Number 03OG026 | 93037
Dimensions - mm 1334 x 891 x 815
Rated voltage (primary, secondary)  230 V / 50 Hz, 12 V / AC
Power consumption - W 5 W
Net weight 110.000 kg
Guarantee (+ request guarantee) - years 2 + 1 Years
Guarantee UVC 2 years
Total number of filter foams – pc. 18 Units
Number of blue filter foams – pc. 4 Units
Number of red filter foams – pc. 7 Units
Number of purple filter foams – pc. 7 Units
Special filter granulate – kg 14.5 kg
Temperature display No
Coarse dirt separation – micrometres 300 µm
Connection inlet - mm 25 / 32 / 38 / 50 mm
Connection inlet 1", 1 ¼", 1 ½", 2"
Connections outlet 2", DN 110
Connections, sludge discharge DN 75
Max. flow rate - l/h 17500 l/h
Suitable for ponds up to max. – m³ 145 m³
Suitable for ponds with fish stock – m³ 72 m³
Suitable for ponds with koi – m³ 36 m³
Connection to Bitron C 36 - 110 W, Bitron Eco 120 - 240 W
